2000l Double Planetary Mixer For Lithium Battery Slurry Production
The double planetary power dispersion mixer (battery model) is composed of two groups of low-speed agitators and two groups of high-speed dispersors, which has a good mixing and dispersion effect.
Description
The double planetary power dispersion mixer (battery model) is composed of two groups of low-speed agitators and two groups of high-speed dispersors, which has a good mixing and dispersion effect. The dispersion line speed of the high speed disperser is above 23m/s, which can effectively control the viscosity and fineness of the slurry. The 3D design of twist type mixing blade, processed by five-axis machining center, can ensure the clearance between blade and blade, blade and barrel wall, blade and barrel bottom, reduce the mixing dead Angle, and improve the uniformity of finished products; Advanced equipment manufacturing process, eliminate metal pollution, greatly improve the safety performance of lithium batteries; High viscosity kneading, slurry solid content can be in the range of 55% and 90%, viscosity up to 100,000mpa.s, the machine is the core equipment of lithium battery industry pulp homogenization.
Mixing barrel positioning adopts twisted type design, accurate positioning in 360 degree direction, and hydraulic lock barrel device: with guide rail to achieve cylinder lifting, accurate positioning, safe and reliable; Bucket support device: wedge structure, no pressure relief, no barrel drop, with safety interlock, can be set to prevent misoperation.
|
Technology Parameters Of 2000L Powerful Dispersing Machine |
|
|
Items↓ Model→ |
2000L |
|
1. Tank Capacity/L |
2000L |
|
2. Tank design size/L SS304 |
Φ 1300*1500mm(2230L) |
|
3. Rotary r/min (frequency control) |
Stirring speed: 0-23r/min |
|
4. Low speed shaft |
Inverted "E" shape paddle |
|
5. High speed shaft |
Double high speed shaft, SU304 two Φbutterfly disc&dispersion discs |
|
6. Power (KW) |
45kw x 2, 37kw |
|
7. Power supply |
AC: 3*380V, 50HZ |
|
8. Non load vacuum |
Inner tank: -0.09Mpa |
|
10. Measurement/mm(L*W*H) |
2400*1600*3500mm |
|
11. Comments |
Most parameters can be customized as buyer's request |
YUSHUN supports customers to bring and send materials experiment, free of charge! ! ! If you want to find the suitable mixer for laboratory, pleas contact us.
